Wizards

Different wizard modules allow the generation of NURBS surfaces from curves and parameters. In particular there are modules for:

  1. Sail design. Bermuda mainsail and jib/genoa, symmetrical and asymmetrical spinnakers from standard measurements parameters. Output of real and rated areas (Spanish RN and IMS).
  2. Appendages design. Keel, rudder and bulb from a profile curve and up to three foil shapes (NACA 4 & 5 digit series).
  3. Extrusion/Revolution surfaces design. Generation of surfaces by extrusion or revolution of a master curve along/around an axis.
