Velocity prediction program

This module takes as input the set of calculations produced by the LPP and produces a set of aero and hydrodynamics parameters for a desired range of wind speed and direction. These prediction includes overall yacht speed, heeling and leeway angles, drive and resistance forces, etc. Different model may be used for the calculations including the IMS aero and the DSYHS hydro models. Crew weight and position (seated, hiking, trapeezing) can be configured. A complete data report is generated.
